Zinc anode TYPE 55 AL, B110555
Article: B110555
- Total length: 350mm/13.78in
- Width: 113mm/4.45in
- Height: 33mm/1.3in
- Hole distance: 310mm/12,20in
- Net weight: 5,1kg/11,24lb
- Gross weight: 5,5kg/12,13lb
- Reinforcement: Aluminium
PCS | Discount | Price |
---|---|---|
5 | 5 % | 540,55 kr /st |
10 | 10 % | 512,10 kr /st |
20 | 15 % | 483,65 kr /st |
50 | 20 % | 455,20 kr /st |
Product description
Product specification
Type 55 Zinc anode
Material: Zinc
Alloy: MIL-DTL-18001L - Zn
Item: B110555
- Weight: 5.5 KG
- Reinforcement: Steel
- C-C: 310mm
- Bolt hole: 12x20mm
- Total length: 350mm
- Length: 260mm
- Width: 113mm
- Height: 33mm
Application area:
- Ship hull
- Port
- Slip
- Cable
- Pipeline
- Dykdalb
- Pump
- Pontoons
- Bridges
- Pillars
Zinc anodes are mainly used in seawater and brackish water. Zinc anodes can be used in brackish water if the resistivity is not too high (approx. 1.5 Ωm). Zinc is more chemically stable than Aluminum and is therefore preferred by many in slightly brackish water environments.
The term "zinc" has become synonymous with sacrificial anodes, since zinc was the original material used for this purpose. But other metals, such as aluminum and magnesium, also act as sacrificial anodes.
With over 30 years of experience, you as a customer can always feel safe with our products. We manufacture everything according to international standards and industry guidelines. Each batch of anodes undergoes rigorous testing and quality assurance, and has been for over 30 years...
Are you unsure about what type of material to use? Ask us, we can!
Technical data
- Capacity: 780 Ah/kg
- Consumption: 11.2 kg/A year
- Specific weight: 7.13 kg/dm³
- Potential: -1,030 mV rel Ag/AgCl in seawater
Typical chemical composition, MIL-DTL-18001L - Zn
Materials | % by weight |
Aluminum (Al) | min 0.10, max 0.5 |
Cadmium (Cd) | min 0.025, max 0.07 |
Steel (Fe) | max 0.005 |
Copper (Cu) | max 0.005 |
Lead (Pb) | max 0.006 |
Other (each) | max 0.10 |
Zinc (Zn) | Remaining |
Information
Extend the lifespan of your marine investments, check the product description for more information.
